Introduction to Tag-Connect

Tag-Connect is an innovative solution that simplifies the process of connecting debuggers, programmers, and test equipment to your printed circuit boards (PCBs). Its patented connectors offer a secure and reliable connection while saving space and cost on every board.

How Tag-Connect Works

Tiny footprint

Tag-Connect cables work by connecting directly to a small footprint of pads and holes on your PCB. The footprint can be as small as an 0805 resistor, and it doesn't require any special PCB finish.

No mating connector required

With Tag-Connect, there's no need for a mating connector or component. The PCB itself serves as the mating connector, further reducing space requirements and costs.

Space and cost savings

Tag-Connect eliminates the need for a programming or test header, JTAG connector, or other traditional connectors on your PCB. This not only saves you the cost of the connector but also frees up valuable PCB real estate.

Reliability of Tag-Connect

Pogo-pin connections

Tag-Connect connectors use pogo-pins (spring-pins) to establish a reliable electrical connection. This ensures a trustworthy connection that lasts as long as needed.

Long-lasting connectors

Tag-Connect connectors are designed for repeated use, just like conventional connectors. In fact, the pogo-pins used in Tag-Connect connectors have been tested to last for well over 100,000 operations. The ribbon cable is typically the first component to fail.

Types of Tag-Connect Cables

Tag-Connect cables come in different versions to suit various needs:

Legged

Legged Tag-Connect cables feature a Tag-Connect connector on one end and a traditional connector on the other. They snap into a custom-designed footprint on the PCB.

No Legs

No Legs Tag-Connect cables have the same configuration as Legged cables, but they don't have the snap-in feature. Instead, they rely on external pressure to maintain the connection.
