Overview
Embed your design with a two-digit green 14-segment alphanumeric display using the AlphaNum G Click Board™. The Click Board™ features two TLC5926 16-bit constant-current LED sink drivers. It contains a 16-bit shift register and data latches, which convert serial input data into a parallel output format. It has a dual-character LED 14-segment display (also known as a starburst display) with two additional segments for decimal points or periods.
It is designed to display letters and numbers and provides a clear, legible LED display. The G in the name of this Click Board™ stands for green.
The AlphaNum G Click Board™ communicates with the target board via MikroBUS RST, CS, SCK, MISO, MOSI, PWM and INT pins (marked here as LE2, LE1, CLK, DOUT, DIN, NUMSEL and NUMSEL# respectively). It is designed to support a 3.3V or 5V power supply, selectable through a solder jumper.
The AlphaNum G Click Board™ is a simple solution for adding 14-segment alphanumeric display to your device. The board carries two TLC5926 16-bit Constant-Current LED sink Drivers as well as a dual character green LED 14-segment display (with two additional segments for commas).
The AlphaNum G Click Board™ communicates with the target board through mikroBUS RST, CS, SCK, MISO, MOSI, PWM and INT pins (marked here as LE2, LE1, CLK, DOUT, DIN, NUMSEL and NUMSEL# respectively). The board is designed to use either a 3.3V or 5V power supply.
| Overview | |
|---|---|
| Category | LED Segment |
| Applications | 14-segment displays, also known as starburst displays, are capable of legibly rendering the ISO Latin alphabet |
| Key components | |
| On-board modules | TLC5926, dual character green LED 14-segment display |
| Features | |
| Key features | Two additional segments for commas. Two TLC5926 16-bit shift registers |
| Interfaces | |
| Interface | SPI, GPIO |
| Compatibility | mikroBUS™ |
| Electrical | |
| Input voltage | 3.3V or 5V |
| Physical | |
| Click board size | L (57.15 x 25.4 mm) |
| Compliance | |
| Country of origin | Serbia |
| RoHS | Compliant |
| Ordering information | |
| Part number (SKU) | MIKROE-1851 |
| Manufacturer | Mikroelektronika d.o.o. |
| EAN | 8606015076317 |
| Warranty | 12 months |
| Shipping weight | 0.031 kg |
-
