Matrix RGB Click Board™
Matrix RGB Click Board™
SKU: MIKROE-2239
Couldn't load pickup availability
Overview
The Matrix RGB Click Board™ is a mikroBUS add-on board powered by a 32-bit FT900 MCU designed specifically for powering 16x32 RGB LED matrices. The board has a 16 wire IDC connector for connecting to a single 16x32 LED panel; however, the firmware inside the FT900x chip can drive more than one panel. Multiple panels can be connected to each other into a daisy-chain configuration (see the video).
The Matrix RGB Click Board™ is a mikroBUS add-on board powered by a 32-bit FT900 MCU designed specifically for powering 16x32 RGB LED matrices. The board has a 16 wire IDC connector for connecting to a single 16x32 LED panel; however, the firmware inside the FT900x chip can drive more than one panel. Multiple panels can be connected to each other into a daisy-chain configuration (see the video).
| Overview | |
|---|---|
| Category | LED Matrix |
| Applications | Driving up to 16 16x32 RGB LED panels (more than 32 is possible, but flickering may occurr) |
| Key components | |
| On-board modules | 32-bit FT900 MCU |
| Features | |
| Key features | Can drive up to 16 panels of 16x32 RGB LEDs, Removes the load from the host MCU |
| Interfaces | |
| Interface | SPI, GPIO |
| Compatibility | mikroBUS™ |
| Electrical | |
| Input voltage | 3.3V |
| Physical | |
| Click board size | M (42.9 x 25.4 mm) |
| Compliance | |
| Country of origin | Serbia |
| RoHS | Compliant |
| Ordering information | |
| Part number (SKU) | MIKROE-2239 |
| Manufacturer | Mikroelektronika d.o.o. |
| EAN | 8606015078311 |
| Warranty | 12 months |
| Shipping weight | 0.02 kg |
-
