IPD - TPD2015 Click Board™

IPD - TPD2015 Click Board™

8-Channel, High-Side 500mA Inductive Load Drivers

SKU: MIKROE-6074

Regular price
£29.00 exc VAT
£34.80 inc VAT
Regular price £20.00 GBP Sale price
£29.00 exc VAT
£34.80 inc VAT
Sale Sold out
Shipping calculated at checkout.
If no stock shown above, check availability

Payment methods

  • American Express
  • Visa
  • Mastercard
  • Maestro
  • PayPal
  • Apple Pay
  • Google Pay
  • Bank transfer
View full details

Key Features

High-side load switch, CMOS/TTL logic control, protection features, suitable for inductive and resistive loads, inductive load of 50mH max, 0.5A output current per channel, can drive load directly, high-voltage operation, and more
Based on the High-side load switch, CMOS/TTL logic control, protection features, suitable for inductive and resistive loads, inductive load of 50mH max, 0.5A output current per channel, can drive load directly, high-voltage operation, and more
Ideal for developing wearable technology, smart home devices, robotics, and AR/VR applications

Overview

Introducing the IPD Click Board™: Revolutionize Your Industrial Automation!

Say hello to the future of industrial automation with the IPD Click Board™! This compact add-on board is your ultimate solution for controlling inductive and resistive loads in the most demanding applications.

Unleash the Power of Precision:

  • TPD2015FN High-Side Switch: Featuring an 8-channel high-side switch with MOSFET outputs from Toshiba Semiconductor, the IPD Click Board™ ensures precision and reliability in load management.
  • Versatile Compatibility: Directly compatible with CMOS and TTL logic, this board is perfect for driving motors, lamps, and industrial programmable logic controllers with ease.

Safety First, Always:

  • Built-in Protection: With overcurrent and overheating protection, the IPD Click Board™ guarantees system stability and safety even under the most challenging operating conditions.
  • Robust Design: Supports inductive loads up to 50mH with a current capacity of 0.5A per channel, ensuring smooth operation in any industrial setting.

Seamless Integration, Effortless Setup:

  • Flexible Connectivity: Accepts an external power supply ranging from 8-24V, offering you the flexibility you need for your projects.
  • Easy Setup: Pre-configured jumpers and load decoupling diodes make setup a breeze, saving time and effort.

Unparalleled Compatibility and Customization:

  • mikroBUS™ Compatible: Fully compatible with the mikroBUS™ socket, the IPD Click Board™ can be used on any host system supporting the mikroBUS™ standard.
  • Open-Source Libraries: Comes with the mikroSDK open-source libraries, providing unmatched flexibility for evaluation and customization.
Overview
CategoryRelay
ApplicationsIdeal for developing wearable technology, smart home devices, robotics, and AR/VR applications
Key components
On-board modulesTPD2015FN - 8-channel high-side load switch featuring MOSFET outputs from Toshiba Semiconductor
Features
Key featuresHigh-side load switch, CMOS/TTL logic control, protection features, suitable for inductive and resistive loads, inductive load of 50mH max, 0.5A output current per channel, can drive load directly, high-voltage operation, and more
Interfaces
InterfaceGPIO
ClickIDYes
CompatibilitymikroBUS™
Electrical
Input voltage3.3V or 5V, External
Physical
Click board sizeL (57.15 x 25.4 mm)
Compliance
Country of originSerbia
RoHSCompliant
Ordering information
Part number (SKU)MIKROE-6074
ManufacturerMikroelektronika d.o.o.
EAN8606032292905
Warranty12 months
Shipping weight0.02 kg
  • 1 × IPD - TPD2015 Click Board™

Contact us to confirm the full contents of the box.
