Overview
Now easily connect your prototype or development board to an oscilloscope or other monitoring devices using the EasyTEST Board. It acts as a complete and cost-effective solution to deal with your connection problems. The simple adapter board has 10 port pins, labelled D0-D7, VCC, and GND. It splits a female 2x5-pin header into two 2x5-pin male headers connected in parallel, with the same pinout as the original system.
IDC10 Splitter Board
The splitter for IDC10 connector splits a female 2x5-pin header into two 2x5-pin headers, connected in parallel. It aids in doubling the number of pins of single IDC10 header, and thus enable the user to monitor signals using oscilloscope probes while the PORT is in operation.
| Type | Adapter |
| Applications | The EasyTEST Board is an ideal solution for connecting your prototype or development board to oscilloscope or other monitoring devices |
| On-board modules | female and two male IDC10 connectors |
| Key Features | Female IDC10 connector is compatible with mikroE development boards |
| Interface | GPIO |
| Compatibility | IDC10 |
| Input Voltage | 3.3V or 5V |
| Overview | |
|---|---|
| Applications | The EasyTEST Board is an ideal solution for connecting your prototype or development board to oscilloscope or other monitoring devices |
| Product type | Adapter |
| Key components | |
| On-board modules | female and two male IDC10 connectors |
| Features | |
| Key features | Female IDC10 connector is compatible with mikroE development boards |
| Key benefits | Flexible solution suitable for all MCU architectures |
| Interfaces | |
| Interface | GPIO |
| Compatibility | IDC10 |
| Electrical | |
| Power supply | 3.3V or 5V |
| Compliance | |
| Country of origin | Serbia |
| RoHS | Compliant |
| Ordering information | |
| Part number (SKU) | MIKROE-260 |
| Manufacturer | Mikroelektronika d.o.o. |
| EAN | 8606015070995 |
| Warranty | 12 months |
| Shipping weight | 0.004 kg |
-
