Hantek HT3325 Programmable Power Supply 2 x 0-32V, 0-5A; 1.8-5.0V, 3A
Hantek HT3325 Programmable Power Supply 2 x 0-32V, 0-5A; 1.8-5.0V, 3A
Regular price
£600.00
inc VAT
£500.00
exc VAT
Regular price
Sale price
Unit price
per
£600.00
inc VAT
£500.00
exc VAT
Shipping calculated at checkout.
If no stock shown above, Order NOW to ship within 10 working days
Couldn't load pickup availability
The Hantek HT3325 is a new generation DC stable power supply we launched, which can be program-controlled. It has a USB program control interface and can output arbitrary voltage or current value; uses LED to display the working state of power; uses large scale integrated circuit, supplies 3 circuits voltage output,voltage-stabilization values and current-stabilization values of circuit 1 and circuit 2 can be changed step by step, the two working states of steady voltage and steady current can be changed automatically with the change of load. The output of circuit 1 and circuit 2 can be in series, in parallel and work independently. The third circuit supplies the optional 4 kinds of output voltage,1.8V、2.5V、3.3V、5V, and supplies overload protection.
View full details
Features
- 3-circuit high precision power independent controllable output:
- 32V/5A(32V/3A) these 2 circuits can be adjusted arbitrarily,1 circuit can be switched to 1.8V/2.5V/3.3V/5V/3A
- 5-bit voltage and 4-bit current display,the minimum resolution is 10mV，1mA
- 3 kinds of output mode:independent,series and parallel connection,support timing output and SCPI remote command
- All digital control,low drift
- Nixie tube to display voltage,current and power
- Memory replay function
- Constant voltage and constant current automatic switching
- 3 kinds of output:independent,series and parallel modes,increase the range of output power
- Digital knob adjustment;can coarse control,fine control;easy to set,intuition output
- Fan speed control
- USB interface,5V1AUSB charge and output interface
- Support timing output function,can achieve 10 sets of timing settings and output control
- 5 groups of system parameters save/call inside, support data storage space expansion
