Overview
The Maynuo M9812B is designed for simulating LED loads for LED driver applications and can simulate loads up to 300W and 500V.
Downloads
Der Maynuo M9812B ist für die Simulation von LED-Lasten für LED-Treiberanwendungen konzipiert und kann Lasten bis zu 300 W und 500 V simulieren.
| Input ratings | |
|---|---|
| Input power | 300 W |
| Input current | 0 to 15 A |
| Input voltage | 0 to 500 V |
| Modes | |
| Operating modes | CC, CR, CV, CW, CC+CV and CR+CV |
| LED mode | Supported, for LED driver testing |
| CC mode current ranges | 0 to 3 A and 0 to 15 A |
| CV mode voltage ranges | 0.1 to 19.999 V and 0.1 to 500 V |
| CW mode power range | 0 to 300 W |
| Performance | |
| CC mode accuracy | 0.03% + 0.05% FS |
| CV mode accuracy | 0.03% + 0.02% FS (0.1 to 19.999 V range); 0.03% + 0.05% FS (0.1 to 500 V range) |
| Voltage measurement accuracy | 0.015% + 0.03% FS (0 to 19.999 V range); 0.015% + 0.05% FS (0 to 500 V range) |
| Current measurement accuracy | 0.03% + 0.05% FS (0 to 3 A range); 0.03% + 0.08% FS (0 to 15 A range) |
| Dynamic test | Transition frequency 0 to 25 kHz; current slew rate 2.5 A/µs; T1 and T2 60 µs to 999 s |
| Protection | |
| Protections | Over current, over voltage, over power, over temperature and reverse polarity |
| Interfaces | |
| Serial interfaces | RS232, RS485 and USB |
| External trigger | Input or output supported |
| Physical | |
| Dimensions | 214 x 108 x 365 mm (W x H x D) |
| Environmental | |
| Operating temperature | 0 to 40 °C |
| Non-operating temperature | -10 to 70 °C |
| Ordering information | |
| Part number (SKU) | M9812B |
| Manufacturer | Maynuo Elektronik Co Ltd |
| EAN | 5055383697182 |
| Warranty | 12 Monate |
| Shipping weight | 6.5 kg |
-
1 ×
Maynuo M9812B 300 W, 500 V, 15 A LED Elektronischer Lastsimulator
