PULSE Click-Platine

PULSE Click-Platine

Impuls-/Signalerzeugung

SKU: MIKROE-2032

Normaler Preis
€37,95 EUR exc tax
Normaler Preis Verkaufspreis
€37,95 EUR exc tax
Sale Ausverkauft
Versand wird beim Checkout berechnet
If no stock shown above, check availability

Zahlungsmethoden

  • American Express
  • Visa
  • Mastercard
  • Maestro
  • PayPal
  • Apple Pay
  • Google Pay
  • Banküberweisung
Vollständige Details anzeigen

Overview

The Pulse Click Board™ features the NE555 timer/pulse generator by Texas Instruments. This pulse generator comes with an adjustable frequency configured in two steps. The circular central switch integrated into the middle of the board is used to first choose between four frequency bands with the aid of a frequency selector. Once the appropriate position is selected, the required output frequency is fine-tuned using the onboard potentiometer in a range between 0.05 Hz and 1000 Hz. The high-precision NE555 timer is designed to produce highly accurate time delays or oscillation. The resulting output can be configured to be sent either as a digital signal through the OUT pin or an interrupt (INT pin). The Pulse Click Board™ is designed to operate using either a 3.3V or 5V power supply only. With precise frequency control, it produces pulse generation for equipment testing and similar purposes.

With such features, the Pulse Click Board™ makes an ideal option for applications like fingerprint biometrics, iris biometrics, RFID reader, and so on.

Das Pulse Click Board™ verfügt über den NE555-Timer/Impulsgenerator von Texas Instruments. Dieser Impulsgenerator verfügt über eine einstellbare Frequenz, die in zwei Stufen konfiguriert werden kann. Der in der Mitte der Platine integrierte kreisförmige zentrale Schalter dient zunächst dazu, mithilfe eines Frequenzwählers zwischen vier Frequenzbändern zu wählen. Sobald die entsprechende Position ausgewählt ist, wird die erforderliche Ausgangsfrequenz mithilfe des integrierten Potentiometers in einem Bereich zwischen 0,05 Hz und 1000 Hz fein abgestimmt. Der hochpräzise NE555-Timer ist darauf ausgelegt, hochgenaue Zeitverzögerungen oder Schwingungen zu erzeugen. Die resultierende Ausgabe kann so konfiguriert werden, dass sie entweder als digitales Signal über den OUT-Pin oder einen Interrupt (INT-Pin) gesendet wird. Das Pulse Click Board™ ist für den Betrieb mit einer 3,3-V- oder 5-V-Stromversorgung ausgelegt. Mit präziser Frequenzsteuerung erzeugt es Impulse für Gerätetests und ähnliche Zwecke.

Mit solchen Funktionen ist das Pulse Click Board™ eine ideale Option für Anwendungen wie Fingerabdruck-Biometrie, Iris-Biometrie, RFID-Lesegeräte usw.

Overview
CategoryClock generator
ApplicationsPulse generation with precise frequency control for equipment testing and similar purposes
Key components
On-board modulesNE555 precision timer
Features
Key featuresSelectable output. Switches and potentiometers for setting up frequency (range from 0.5Hz to100 kHz)
Interfaces
InterfaceGPIO
CompatibilitymikroBUS™
Electrical
Input voltage3.3V or 5V
Physical
Click board sizeM (42.9 x 25.4 mm)
Compliance
Country of originSerbia
RoHSCompliant
Ordering information
Part number (SKU)MIKROE-2032
ManufacturerMikroelektronika doo
EAN8606015077376
Warranty12 Monate
Shipping weight0.03 kg
  • 1 × PULSE Click-Platine

Contact us to confirm the full contents of the box.
