Embed your design with a two-digit green 14-segment alphanumeric display using the AlphaNum G Click Board™ . The Click Board™ features two TLC5926 16-bit constant-current LED sink drivers. It contains a 16-bit shift register and data latches, which convert serial input data into a parallel output format. It has a dual-character LED 14-segment display (also known as a starburst display) with two additional segments for decimal points or periods.
It is designed to display letters and numbers and provides a clear, legible LED display. The G in the name of this Click Board™ stands for green.
The AlphaNum G Click Board™ communicates with the target board via MikroBUS RST, CS, SCK, MISO, MOSI, PWM and INT pins (marked here as LE2, LE1, CLK, DOUT, DIN, NUMSEL and NUMSEL# respectively). It is designed to support a 3.3V or 5V power supply, selectable through a solder jumper.
