Features
- Linux based system allows for easy adaption of network protocols and remote support options.
- Multi SDF capable, you can switch between different LIN bus configurations by just loading another SDF form the internal flash drive.
- Connection to PLC or host system via ethernet connection or RS-232.
- SDF files or firmware updates are installed on the device by using an USB stick.
- Base version integrated LIN1, LIN2, CAN-High-Speed, RS-232, LAN interface hardware.
- Base version supports LIN1 interface (including SDF-V3), LIN2 and CAN support can be activated by separate sold activation keys.
- 2 internal MIF module slots for extension, MIF-LIN-02 module with 2 LIN interfaces allows a total of 6 LIN lines in one device.
- Digital input and digital output available.
- Secure shut down due to integrated USV (15 seconds hold-up time).
- Optional compatibility adapter converts new Sub-D-25 connector pinning to 2 * Sub-D-9 connector pinning of Baby-LIN-MB.
Technical Function
- Supports LIN bus versions 1.2, 1.3, 2.0, 2.1 and 2.2, as well as CAN high-speed, RS-232 and LAN interface
- LIN interface with 2 MIF-LIN-02 modules and a total of 6 LIN channels
- Input and output with 24V signal for synchronisation purposes
- Integrated UPS with 15 seconds bridging time
- Galvanically isolated LIN and CAN bus interface
- MicroSD card up to 32 GB
- On-board voltages from 8 - 28V
Application Areas
- Application of network protocols and remote maintenance functions for Industry 4.0
- Control of different interfaces via multi SDF capability and 6 LIN bus configurations
- Can be used
