The Acute Technology TravelScope TS3000 Series is a compact, PC-based digital storage oscilloscope designed for engineers who need bench-grade measurements on the move. Via a single USB 3.0 connection, it delivers four analogue channels, 200 MHz bandwidth and up to 1 GS/s real-time sampling. A deep 128 Mpts record length per channel supports long acquisitions without sacrificing resolution.
TS3000 also integrates a 3-digit digital voltmeter and 5-digit frequency counter, plus a data-logger that streams to your PC’s SSD or HDD. For higher channel counts, DSO Stack Mode lets you combine multiple units for time-aligned capture. Developers can automate and integrate measurements using the available SDK.
Series options
Choose from TS3124E, TS3124B, TS3124H and TS3124V. The H/V variants add high-resolution modes, while TS3124V enables protocol trigger/decode and electrical validation for modern power-management buses. Pairing TS3000 with an Acute logic analyser enables mixed-signal (analogue + digital) debug. See the Acute TravelLogic Logic Analyser for a complementary solution.
Why consider TS3000?
It combines portable hardware with deep memory, multi-unit scaling and integrated DVM/counter—ideal for embedded, power and interface debug when a full bench scope is impractical.
