| Model | Channels | Bus Triggers | Protocol Analysis Options |
|---|---|---|---|
| LA4068E | 68 Channels | I | I |
| LA4068B | 68 Channels | I, II | I, II |
| LA4136E | 136 Channels | I | I |
| LA4136B | 136 Channels | I, II | I, II |
Protocol Trigger I: 10BASE-T1S¹, BiSS-C, CAN2.0B/CAN FD, DP_Aux¹, HID over I2C, I2C, I2S, LIN2.2, MIPI I3C 1.1, SENT, SPI, UART (RS232), USB PD 3
Protocol Trigger II: 10BASE-T1S¹, BiSS-C, CAN2.0B/CAN FD, DP_Aux¹, HID over I2C, I2C, I2S, LIN2.2, MIPI I3C 1.1, SENT, SPI, UART (RS232), USB PD 3, DALI, eMMC 4.5, eSPI, HyperBus, LPC, MDIO, MII, Mini/Micro LED, MIPI RFFE 3, MIPI SPMI 2, Modbus, NAND Flash, PMBus, Profibus, RGMII, RMII, SD 3.0 (SDIO 2.0), SENT, Serial Flash (SPI NAND), SMBus, SVI2, SVID³, USB1.1
Protocol Analyzer I: 10BASE-T1S¹, BiSS-C, CAN2.0B/CAN FD, DP_Aux¹, HID over I2C, I2C, I2S, LIN2.2, MIPI I3C 1.1, SPI, UART (RS232), USB PD 3
Protocol Analyzer II: 10BASE-T1S¹, BiSS-C, CAN2.0B/CAN FD, DP_Aux¹, HID over I2C, I2C, I2S, LIN2.2, MIPI I3C 1.1, SPI, UART (RS232), USB PD 3, DALI, eSPI, MDIO, MII, MIPI RFFE 3, Modbus, PMBus, Profibus, RGMII, RMII, SMBus, SVID³, USB1.1
Protocol Decode : 1-Wire, 3-Wire, 7-Segment, 10BASE-T1S¹, A/D Mux Flash, AccMeter, ADC, APML, AVSBus, BiSS-C, BSD, BT1120, CAN 2.0B/FD, Close Caption, CODEC_SSI, DALI, DMX512, DP_Aux¹, EDID, eMMC 4.5, eSPI, FlexRay, HD Audio, HDLC, HDQ, HID over I²C, HTSensor, HyperBus, I²C EEPROM, I²C, I²S (PCM, TDM), I80, IDE, IO-Link, IrDA, ISELED, ITU-R BT.656 (CCIR656), JTAG, JVC IR, LCD1602, LED_Ctrl, LIN 2.2, Line Decoding, Line Encoding, Lissajous, LPC, LPT, Math, M-Bus, MDDI, MDIO, MHL CBUS, Microchip SWI, Microwire, MII, Mini/Micro LED, MIPI CSI LP, MIPI DSI LP, MIPI I3C 1.1, MIPI RFFE 3, MIPI SoundWire 1.2, MIPI SPMI 2, Modbus, NAND Flash, NEC IR, PDM, PECI 3.0, PMBus, Profibus, PS/2, PWM, QEI, QI, QSPI, RC-5, RC-6, RGB Interface, RGMII, RMII, S/PDIF, SD 3.0 (SDIO 2.0), SENT, Serial Flash, Serial IRQ, Serial PSRAM, SGPIO, Smart Card, SMBus (SBS, SPD), SMI, SPI, SPI-NAND, SSI, ST7669, SVI2, SVID², SWD, SWIM, SWP, UART (RS232), ULPI, UNI/O, USB 1.1, USB4/TBT3 SB Channel, USB PD 3, Wiegand, ...
